Agilent (Keysight) 34450A Digital Bench Multimeter

Agilent (Keysight) 34450A is a high-precision 5.5-digit digital bench multimeter designed for measuring various electrical parameters with high speed and accuracy.

Main Specifications:

• Resolution: 5.5 digits
• Measurement speed: up to 190 readings per second
• Basic DC voltage accuracy (1 year): 0.015%
• Measurement functions:
  • DC Voltage (DCV)
  • DC Current (DCI)
  • AC Voltage (ACV) with True RMS
  • AC Current (ACI) with True RMS
  • Resistance (2- and 4-wire measurement)
  • Frequency
  • Capacitance
  • Temperature
  • Continuity testing
  • Diode testing
• Display: dual-line high-contrast OLED display
• Memory: up to 50,000 data points for data logging
• Interfaces for PC connection:
  • USB 2.0
  • RS-232
  • GPIB (optional)

Features:

• Built-in histogram and basic statistics functions for simplified data analysis.
• Compatibility with SCPI commands and Fluke 45 and Fluke 8808A multimeters for easy integration into existing systems.
• Support for remote control and data collection via various interfaces.
